These adapters ensure reliable interoperability between different series of RF coaxial connectors. Available in materials such as brass and stainless steel, they are widely used in modern precision measurement systems and microwave communication equipment.
| Product Specifications | |||
| Product Specifications | Connector Impedance | 75 Ohm | |
| Frequency Range | DC ~ 0.3 GHz | ||
| Working Voltage | 500V | ||
| Dielectric Withstanding Voltage | 1000V | ||
| Insulation Resistance | ≥1000 MΩ | ||
| Center Contact Resistance | ≤1.5 mΩ | ||
| Outer Contact Resistance | ≤0.2 mΩ | ||
| VSWR | ≤1.3 | ||
| Operating Temperature | -65℃~ 165℃ | ||
| Materials & Plating | Component | Material | Plating/Coating |
| F-K | Brass | Nickel | |
| N-J | Brass | Nickel | |
| Insulator | PTFE | - | |
| Pin Contact | Brass | Gold | |
